Asustor LOCKERSTOR 6 Gen2 AS6706T 6-Bays NAS Storage
Specification
Basic Information | ||
Processor | CPU Model: Intel Celeron N5105 CPU Architecture: x64 64-bit CPU Frequency: Quad-Core 2.0GHz (burst up 2.90 GHz) |
|
Memory | Memory: 8GB SO-DIMM DDR4 Memory Module Pre-installed: 8GB (1x 8GB) Total Memory Slots: 2 Memory Expandable: up to 16GB (2x 8GB) Flash Memory: 8GB eMMC |
|
Hard Disk | Drive Bays: 6 M.2 Drive Slots: 4 Compatible Drive Type 3.5″ SATA HDD 2.5″ SATA HDD 2.5″ SATA SSD M.2 2280 NVMe Maximum Drive Bays with Expansion Unit: 14 |
|
RAID Controller | Support Multiple Volumes with Spare Disks Volume Type: Single, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 Support for Online RAID Level Migration |
|
Operating System | Windows 7, 8, 10, 11, Server 2008, Server 2012, Server 2016, Server 2019, Server 2022 macOS UNIX, Linux, and BSD |
|
Peripherals | 2x USB 3.2 Gen 2 (10Gbps) 1x for optional expansion 10 GbE card 1x HDMI 2.0b |
|
Network | 2x 2.5 Gigabit Ethernet (2.5G/1G/100M) | |
Additional Features | ||
Power Supply and Cable | 250W x1 | |
Others | Certification: FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA | |
Manufacture Warranty | ||
Warranty | 03-Years Warranty |
Description
Asustor LOCKERSTOR 6 Gen2 AS6706T 6-Bays NAS Storage
The Asustor LOCKERSTOR 6 Gen2 AS6706T is a high-performance 6-bay NAS (Network Attached Storage) solution designed for home users, small businesses, and power users seeking robust, reliable, and scalable storage for data backup, file sharing, media management, and more. The AS6706T offers a variety of features aimed at improving both storage and security management. Here’s a detailed description of the key features and specifications:
Key Features:
- 6-Bay NAS: The Asustor AS6706T comes with six bays, supporting 3.5-inch or 2.5-inch hard drives and SSDs. This gives users the flexibility to install multiple drives and configure them for various RAID setups, including RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, and JBOD. This scalability ensures optimal performance and data protection, with the ability to expand storage as needs grow.
- Intel Celeron J4125 Processor: The AS6706T is powered by an Intel Celeron J4125 quad-core processor, clocked at 2.0 GHz (up to 2.7 GHz in burst mode). This processor delivers excellent performance for multitasking and handling demanding applications such as media streaming, file syncing, and virtualization.
- 4GB DDR4 RAM (expandable): The NAS comes with 4GB of DDR4 RAM, providing fast access to data and applications. The memory is expandable up to 8GB, which is ideal for users running multiple applications or accessing large amounts of data simultaneously.
- High-Speed Network Connectivity: The AS6706T is equipped with dual 2.5GbE Ethernet ports, offering fast and reliable network speeds for data transfer. This makes it ideal for high-demand tasks such as media streaming, file sharing, and remote access. Additionally, the NAS supports Link Aggregation for even higher speeds and redundancy.
- 4K Media Streaming: With its high processing power and dual 2.5GbE networking, the AS6706T excels in media streaming, supporting up to 4K video transcoding. This makes it an excellent choice for users who want to store and stream high-quality video content to various devices around the home or office.
- Comprehensive Data Protection: The Asustor AS6706T offers robust data protection features, such as RAID support, automatic snapshots, data encryption, and remote replication. These features ensure that your data is secure, protected from hardware failure, and can be easily restored if needed.
- Versatile Expansion Options: The NAS includes USB 3.2 Gen 1 and USB 3.2 Gen 2 ports for connecting external devices such as additional storage drives, printers, or even UPS (uninterruptible power supplies). It also has PCIe expansion slots, allowing users to install additional network cards or SSD cache to boost performance.
- Asustor ADM Operating System: The AS6706T runs on Asustor’s ADM (Asustor Data Master) operating system, which provides an intuitive web-based interface for easy configuration and management. ADM includes features such as cloud access, mobile apps, multimedia management, backup and recovery tools, and a wide variety of third-party apps from the Asustor App Central marketplace.
- Energy-Efficient Design: The NAS has an energy-efficient design, with intelligent fan control and low-power components that minimize energy consumption, making it suitable for 24/7 operation without significant electricity costs.
- Surveillance Station Support: Asustor’s NAS systems support Surveillance Station, which allows users to turn the AS6706T into a robust network video recorder (NVR) for monitoring security cameras and recording video footage.
- Remote Access and Cloud Sync: With built-in Asustor EZ Connect and cloud synchronization features, the AS6706T can be accessed remotely via web browsers or mobile apps, providing users with seamless access to their data and files from anywhere.
Applications:
- Home Office / Small Business: Ideal for users who need centralized data storage, secure backup, file sharing, and media streaming.
- Media Enthusiasts: Perfect for those who wish to store, organize, and stream large media libraries in 4K.
- Data Backup and Disaster Recovery: Excellent for businesses that require data redundancy, frequent snapshots, and off-site replication for disaster recovery.
- Surveillance: Ideal for use as an NVR (Network Video Recorder) for managing and storing surveillance camera footage.
