BIOSTAR B550MXC PRO DDR4 AMD AM4 Micro ATX Motherboard
Original price was: ৳12,600.৳11,500Current price is: ৳11,500.
Quick Overview
- Model: B550MXC PRO
- Supported CPU: Ryzen 3rd Gen and 4th Gen processors
- Supported RAM: 2x DIMM, DDR4 4933+(OC)
- Graphics Output: 1 x HDMI
- Features: Supports WiFi 6 module
BIOSTAR B550MXC PRO DDR4 AMD AM4 Micro ATX Motherboard
Specification
| Basic Information | ||
| Supported CPU | Socket AM4 support AMD Ryzen 3rd Gen (Matisse/ Renoir) and Ryzen 4th Gen (Vermeer/ Cezanne) processors Support for future AMD Ryzen processors with BIOS update |
|
| Chipset | AMD B550 | |
| Form Factor | Micro ATX Form Factor Dimension: 24.4cm x 20.8cm ( W x L ) | |
| Audio | Realtek ALC897 7.1 Channels, High Definition Audio, Hi-Fi (Front) |
|
| Expansion Slots | ||
| PCI | AMD Ryzen 5000/3000 Series Processors 1 x PCIe 4.0 x16 Slot (x16 or x4/x4/x4/x4 mode) or AMD Ryzen 5000 G/4000 G Series Processors 1 x PCIe 3.0 x16 Slot (x16 or x8/x4/x4 mode) AMD B550 Chipset 1 x PCIe 3.0 x16 Slot (x1 mode) 1 x PCIe 3.0 x16 Slot (x1 mode) 1 x PCIe 3.0 x16 Slot (x1 mode) |
|
| M.2 Socket | 2 x M.2 sockets | |
| Memory | ||
| Type | DDR4 | |
| Slots | 4 x DIMM | |
| Supported Memory | 4th Gen AMD Ryzen Processors (Vermeer CPUs/ Cezanne APUs): Supports Dual Channel DDR4 1866/2133/2400/2666/2933/3200/4533(OC) 3rd Gen AMD Ryzen Processors (Matisse CPUs): Supports Dual Channel DDR4 1866/2133/2400/2666/2933/3200/4533(OC) 3rd Gen AMD Ryzen with Radeon Graphics Processors (Renoir APUs): Supports Dual Channel DDR4 1866/2133/2400/2666/2933/3200/4533(OC) |
|
| Maximum Memory | Up to 128GB | |
| Graphics | ||
| Graphics | By CPU model Supports DX12 Supports HDCP |
|
| Connector & Ports | ||
| HDMI | 1 x HDMI Port | |
| USB (s) | 4 x USB 3.2 (Gen1) Port 2 x USB 2.0 Port 2 x USB 2.0 Header (each header supports 2 USB 2.0 ports) 1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports) |
|
| LAN Port (s) | Realtek RTL8111H 10/ 100/ 1000 Mb/s auto-negotiation, Half / Full duplex capability |
|
| Wireless Communication module | Supports WiFi 6 module | |
| Supported Storage | Total supports 8 x SATA III (6Gb/s) ports and 2 x M.2 sockets 4 x SATA III (6Gb/s) Support AHCI & RAID 0, 1, 5, 10 only for SATA1 ~ SATA4 ports* 2 x M.2 slots (Key M) 1 x M.2 (M Key) Socket (M2_PCIEG4_64G_SATA) (From AMD Processors) Supports PCIe 4.0/ 3.0×4** – NVMe/ AHCI Supports SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices 1 x M.2 (M Key) Socket (M2_PCIEG3_32G_SATA) (From AMD B550 Chipset) Supports PCIe 3.0×4 – NVMe/ AHCI Supports SATA 6Gb/s Supports 2280 storage devices |
|
| Audio | 3 x Audio Jack | |
| Internal I/O Ports | 8 x SATA III (6.0Gb/s) Connector 1 x M.2 (E Key) Socket: Supports 2230 type Wi-Fi & Bluetooth module 1 x 8-Pin Power Connector 1 x 24-Pin Power Connector 1 x CPU Fan Connector 2 x System Fan Connector 1 x Front Panel Header 1 x Front Audio Header 1 x Internal Stereo Speaker Header 1 x Clear CMOS Header 1 x S/PDIF out Connector 1 x COM Port Header 1 x TPM Header 2 x LED Header (5V) 1 x LED Header (12V) 1 x Debug LED |
|
| Others | ||
| Special Features | Supports 100% Solid capacitor BIO-FLASHER A.I FAN PCIe M.2 32Gb/s |
|
| Bundled Software | BullGuard | |
| Warranty Information | ||
| Manufacturing Warranty | 3 Years | |
Description
BIOSTAR B550MXC PRO DDR4 AMD AM4 Micro ATX Motherboard
The BIOSTAR B550MXC PRO DDR4 AMD AM4 Micro ATX Motherboard is an advanced and feature-rich motherboard tailored to meet the needs of gamers, content creators, and everyday PC enthusiasts. Designed with the AMD B550 chipset, it supports the latest AMD Ryzen processors for exceptional processing power, multitasking capabilities, and efficient performance. Compatible with AMD Ryzen 3000, 4000, 5000, and 6000 series processors, this motherboard ensures broad compatibility with the latest CPUs on the market.
The motherboard features dual-channel DDR4 memory support with speeds of up to 4933 MHz (OC), allowing for improved system responsiveness and the ability to run memory-intensive applications seamlessly. It also supports up to 128GB of memory capacity across four DIMM slots, providing excellent upgrade potential for users seeking to expand their system’s memory capabilities. The PCIe 4.0 interface provides faster bandwidth for graphics cards and storage devices, ensuring high-performance gaming, rendering, and multimedia capabilities.
Storage options are plentiful with this Micro ATX motherboard, supporting multiple SATA ports and M.2 NVMe SSDs for lightning-fast data transfer speeds. The inclusion of PCIe slots allows for easy installation of dedicated graphics cards, Wi-Fi adapters, sound cards, or other PCIe-based expansion cards. Additionally, the BIOSTAR B550MXC PRO provides excellent USB connectivity options, including USB 3.2 Gen 1 and 2 ports for quick peripheral connections like external storage drives, keyboards, or gaming accessories.
The motherboard integrates advanced power delivery technology, ensuring stable and efficient power for the CPU and other critical components. This is supported by robust VRMs and quality capacitors to provide enhanced stability, especially when overclocking or under load. Furthermore, it features system monitoring technology to ensure that temperature and voltage remain at optimal levels, preventing overheating or system instability.
The BIOSTAR B550MXC PRO also includes integrated graphics support, allowing users to enjoy smooth visual performance for productivity or casual gaming without the need for a discrete graphics card. Its compact Micro ATX form factor makes it an ideal choice for smaller builds, including home theater systems, small gaming rigs, or space-efficient workstations, without compromising on performance or expandability.
BIOSTAR B550MXC PRO DDR4 AMD AM4 Micro ATX Motherboard Price in BD
The Best price of a BIOSTAR B550MXC PRO DDR4 AMD AM4 Micro ATX Motherboard is 11,000 TK. you can visit Our showroom( Suvastu Arcade ICT Bhaban, Shop: 04,05( Ground Floor), 46-48 New Elephant Road, Dhaka-1205 ) and Join Our Facebook Page.
