GIGABYTE H610M H DDR5 mATX Motherboard
Original price was: ৳12,900.৳11,000Current price is: ৳11,000.
Quick Overview
- Model: H610M H
- Supported CPU: 14th/13th/12th Gen Intel Processors (LGA1700)
- Supported RAM: 2x DDR5, Max 64GB 4800(OC)
- Graphics Output: 1x HDMI, 1x D-Sub port
- Features: Realtek GbE LAN chip (1 Gbps/100 Mbps)
GIGABYTE H610M H DDR5 mATX Motherboard
Specification
| Basic Information | ||
| Supported CPU | LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel Core, Pentium Gold and Celeron Processors L3 cache varies with CPU |
|
| Chipset | Intel H610 Express Chipset | |
| BIOS | 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
| Form Factor | Micro ATX Form Factor; 23.0cm x 21.5cm | |
| Audio | Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel |
|
| Expansion Slots | ||
| PCI | CPU: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 Chipset: 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 |
|
| Memory | ||
| Type | DDR5 | |
| Slots | 2 | |
| Supported Memory | Support for DDR5 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules |
|
| Maximum Memory | up to 64 GB (32 GB single DIMM capacity) of system memory | |
| Graphics | ||
| Graphics | Integrated Graphics Processor-Intel® HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz Support for HDMI 2.1 version and HDCP 2.3. Support native HDMI 2.1 TMDS compatible ports (Graphics specifications may vary depending on CPU support.) |
|
| Connector & Ports | ||
| HDMI | 1x HDMI | |
| D-Sub (s) | 1x D-Sub port | |
| USB (s) | Chipset: 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) 4 x USB 2.0/1.1 ports on the back panel Chipset+USB 2.0 Hub: 4 x USB 2.0/1.1 ports available through the internal USB headers |
|
| LAN Port (s) | Realtek GbE LAN chip (1 Gbps/100 Mbps) | |
| Supported Storage | Chipset: 1 x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 3.0 x4/x2 SSD support) 4 x SATA 6Gb/s connectors |
|
| Audio | 1 x front panel audio header 2 x audio jacks |
|
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x RGB LED strip header 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x serial port header 1 x Clear CMOS jumper |
|
| TPM (Trusted Platform Module ) | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) | |
| Others | ||
| Special Features | Support for APP Center Support for Q-Flash Support for Xpress Install |
|
| Bundled Software | Norton Internet Security (OEM version) LAN bandwidth management software |
|
| Warranty Information | ||
| Manufacturing Warranty | 3 years | |
Description
GIGABYTE H610M H DDR5 mATX Motherboard
The GIGABYTE H610M H DDR5 mATX Motherboard is an entry-level yet powerful motherboard tailored to support Intel’s latest generation processors, making it a strong choice for both gaming and productivity builds. Designed with performance and efficiency in mind, this motherboard features support for cutting-edge DDR5 memory technology, allowing for improved bandwidth and responsiveness, better multitasking capabilities, and optimized system performance. The mATX form factor offers a compact build without sacrificing functionality, allowing it to fit into a variety of system cases while maintaining full compatibility with essential features.
The GIGABYTE H610M H DDR5 incorporates PCIe 4.0 technology, which delivers high-speed bandwidth for next-gen graphics cards and NVMe storage devices, enhancing your system’s responsiveness and storage speeds. With a robust power design and premium capacitors, this motherboard offers stability during peak performance and heavy usage, ensuring reliable operation over time. It features a wide array of connectivity options, including USB ports, SATA 6Gb/s connections, and Gigabit LAN for efficient network connections, peripheral support, and reliable storage options.
Additionally, the GIGABYTE H610M H DDR5 mATX Motherboard supports integrated graphics, allowing users to rely on Intel’s onboard GPU capabilities for light gaming and media tasks without the need for a dedicated graphics card. The motherboard also includes PCI Express slots for system upgrades and expansion, providing flexibility for customization and enhancement. Equipped with advanced thermal management technology, the motherboard maintains optimal operating temperatures, even during demanding computing tasks, thanks to its smart thermal design.
GIGABYTE H610M H DDR5 mATX Motherboard Price in BD
The Best price of a GIGABYTE H610M H DDR5 mATX Motherboard is 11,000 TK. you can visit Our showroom( Suvastu Arcade ICT Bhaban, Shop: 04,05( Ground Floor), 46-48 New Elephant Road, Dhaka-1205 ) and Join Our Facebook Page.
